MX301 Universal Routing Platform Datasheet

Built on Juniper’s Trio 6 silicon, the MX301 brings powerful programmability, deep service scale, and AI-ready interfaces in a space- and energy-efficient chassis.

A single routing engine (RE) on the MX301 runs Junos OS, where it manages all routing protocol processes, router interface control, and control plane functions such as chassis operations, system management, and user access to the router. These processes run on top of a kernel that interacts with the packet forwarding engine (PFE) on modular interface cards (MICs) via dedicated high-bandwidth management channels, providing a clean separation between the control and forwarding planes.

Powered by Juniper’s sixth-generation programmable Trio silicon, the MX301 delivers unprecedented bandwidth in a compact, power-optimized 1RU form factor. Unlike modular systems such as the MX304, the MX301 uses high-density fixed ports rather than MICs, simplifying deployment while providing broad routing, switching, inline services, subscriber management, and hierarchical quality of service (HQoS). With configurations supporting 1 to 400GbE interfaces, the MX301 enables service providers, cloud operators, and enterprises to flexibly and efficiently meet their connectivity requirements without the complexity of modular cards.

The MX301 power and thermal subsystems use advanced technology to optimize power efficiency without sacrificing scale or features. The power subsystem is highly resilient, allowing full power supply and power cable feed redundancy, resulting in industry-leading power consumption efficiency.

Junos OS is a reliable, high-performance, modular network operating system supported across all of Juniper’s physical and virtual routing, switching, and security platforms. It reduces the cost, complexity, and resources required to implement and maintain a Juniper-based network. With secure programming interfaces, the Juniper^® Extension Toolkit (JET), versatile scripting support, and integration with popular orchestration frameworks, Junos OS offers flexible options for continuous delivery and DevOps-style management, helping service providers unlock more value from the network.

The MX301 delivers up to 1.6 Tbps of throughput in a remarkably compact 1RU form factor with flexible 100G/4000G port flexibility, redefining edge efficiency for dense deployments. Its advanced Trio 6 chipset, combined with modular interface flexibility, allows operators to scale out high-bandwidth edge services while reducing space and power needs—achieving industry-leading power usage as low as 0.3W per Gb. This decreases total cost of ownership and enables sustainable growth for next-generation, bandwidth-intensive workloads.

The MX301 incorporates line-rate MACsec and IPsec encryption, as well as Trusted Platform Module (TPM) support, securing traffic at Layers 2 and 3 without compromising performance. Operators benefit from built-in hardware-based encryption for 400GbE and 100GbE ports, safeguarding critical data flows and supporting compliance with regulatory and enterprise security standards. The TPM enables secure device identity and hardware root of trust, further ensuring platform integrity for trusted transport in sensitive or regulated environments.

Purpose-built for the AI era, the MX301’s deterministic latency and high-throughput architecture are ideal for aggregating and forwarding real-time AI and inference traffic. Its programmable Trio 6 silicon, multi-rate port density up to 400GbE, and support for precision time protocol (PTP) deliver predictable, low-latency connectivity—critical for AI edge aggregation, distributed analytics, and latency-sensitive automation. Open APIs and deep telemetry enable integration with AIOps platforms, maximizing both network agility and AI application performance.

The programmable Junos Trio 6 chipset provides the power to monitor and collect data at the component level. The chipset uses the Junos Telemetry Interface to stream this data in a scalable manner to monitoring, analytics, and performance management applications, as well as to path computation elements (PCEs) such as Juniper Networks Paragon Pathfinder. The derived telemetry information identifies current and trending congestion, resource utilization, traffic volume, latency, and delay, helping service providers detect issues and make informed decisions about network design, optimization, and investments.

MX Series routers support highly scalable and reliable hardware-based timing that meets the strictest LTE requirements, including synchronous Ethernet for frequency and the PTP for frequency and phase synchronization.

Synchronous Ethernet and PTP can be combined in a “hybrid” mode to achieve the highest level of frequency (10 ppb) and phase accuracy (< 1.5 uS) required for LTE-Advanced, eliminating the need for external clocks. The MX301 also supports advanced timing standards such as G.8275.1.

The Junos Automation Toolkit, included in the Junos OS software, offers a suite of tools supported on all Juniper Networks switches, routers, and security devices. These tools leverage the native XML capabilities of Junos OS, including commit scripts, operations scripts, event policies and scripts, and macros that automate operational and configuration tasks. Automation saves time by performing repetitive operational and configuration tasks, speeding up troubleshooting, and maximizing network uptime by warning operators of potential problems and automatically responding to system events.

The MX301 Universal Routing Platform delivers a powerful solution for the following use cases.

The MX301 offers the 1GbE, 10GbE, 25GbE, 40GbE, 50GbE, 100GbE, and 400GbE interfaces that large enterprises and service providers need. It also includes a comprehensive VPN toolkit to support feature-rich, standards-based, and secure internetworking for innovative business services. The MX301 delivers deterministic performance with inline MACsec and IPsec encryption, as well as TPM support for trusted transport.

In addition to basic L2/L3 VPN and virtual private LAN service (VPLS) support, the MX301 offers enhanced VPN services such as quality-of-service (QoS)-prioritized VPN traffic for voice and video, L2 VPN internetworking to connect dissimilar L2 access networks, and rich IP/MPLS features to customize services and meet service-level agreements (SLAs).

The MX301 provides outstanding support for metro and aggregation networks by offering a full suite of routing and switching features, allowing network operators to choose a deployment model that best suits their business and technical needs and goals. The MX301 can be deployed as an IP/MPLS VPN edge router, VPLS router, MPLS label-switching router (LSR), or as a Layer 2 Ethernet switch or Layer 3 IP router. The MX301 also supports an extensive set of Ethernet operation, administration, and maintenance (OAM) features and is Metro Ethernet Forum (MEF) certified 3.0.

The compact 1RU form factor and high-bandwidth capabilities of the MX301 make it ideal for large branch offices and enterprise core deployments. With support for up to 1.6 Tbps throughput and a versatile range of interfaces from 1GbE to 400GbE, the MX301 delivers the scale and agility enterprises need to consolidate infrastructure and future-proof their WAN. Integrated inline encryption (MACsec and IPsec) ensures sensitive applications and data remain secure, while Junos OS provides seamless operational consistency across campus and branch networks.

The MX301 is engineered to address the scale and resiliency demands of modern broadband networks, supporting up to 16,000 subscriber sessions in a compact chassis. Its programmability and integrated service functions—including subscriber management, DHCP, PPPoE, and advanced HQoS—allow broadband providers to deliver differentiated services while maintaining high performance at peak load. The system’s low power draw and small footprint make it particularly attractive for distributed locations such as remote central offices and rural broadband rollouts.

Purpose-built for AI-native environments, the MX301 aggregates high-volume, low-latency traffic from distributed edge inference nodes. Its line-rate 400GbE ports and Trio 6 chipset enable deterministic performance for real-time AI applications, including industrial automation, smart cities, and intelligent transportation. Autonomous AI workloads are supported with secure and efficient transport backed by inline MACsec/IPsec and PTP capabilities. Additionally, open APIs and integration with Marvis^® AI allow operators to automate AI edge networking with full telemetry and lifecycle awareness.

Optimized for distributed 5G architectures, the MX301 serves as a high-performance user plane function (UPF), delivering up to 1.6 Tbps throughput with line-rate MACsec and IPsec encryption. It supports 3GPP CUPS with key interfaces (N3/N4/N6/N9) and PFCP-based control for dynamic session management. Compact and power efficient, the MX301 is ideal for edge-located UPFs, enabling ultra-low-latency service delivery for eMBB, IoT, and MEC use cases. Advanced QoS, 5QI/QFI policy enforcement and dual stack 4G/5G support ensure seamless mobile service evolution and full lifecycle automation with Junos OS.

• Physical dimensions: (HxWxD): 1.75 x 17.3 x 17.7 inches (4.45 x 44 x 45 cm)
• 2 PSU FRUs (1+1 Redundancy)
• Power consumption: <500W Typical
• Airflow: Front to back
• 6 Fan FRUs (N+1 Redundancy)
• Maximum weight (approximate): 26 lbs (12 kg)
• System mounting: 2/4-post rack mounting
• Rack units: 1
• NEBS Compliance
• Operating temperatures: 32° to 115° F (0° to 46° C) at sea level
